Support up to 4 operators for co-construction
High system gain and high power output to support 4*46dBm @400M bandwidth
High reliability and stability
Low delay is suitable for 5G TDD system, which support great length for fiber route especially for BTS hotel application
Natural heat dissipation to improve product reliability
Redundant backup and automatically switch over in case of failure to ensure network service
Good dustproof and waterproof performance to support indoor and outdoor installation
N78, 40W, 2T2R, 3300-3700MHz, 5GNR
| Uplink | Downlink | ||
| Frequency Range | n78 (2x2 MIMO) | 3300 - 3700 MHz | 3300 - 3700 MHz |
| Gain | 53 ± 3 dB | 53± 3 dB | |
| Max RF Power | --- | 46 ± 2 dBm | |
| Operating Temperature Range | -40ºC to +55ºC |
| Storage Temperature Range | -40°C to +85°C |
|
Relative Humidity |
5% - 95% |
|
Ingress Protection |
IP67 |
| Monitoring and Control | LAN-RJ45 (local) |
| Optical Connector | 2 x SC/APC | |
| RF Connector (Downlink Output) |
4 x 4.3-10 (ANT1: SISO_L; ANT2: MIMO_L; ANT3: SISO_H; ANT4: MIMO_H)* |
|
| RF Connector (Uplink Input) | 2 x 4.3-10 (ANT1 / ANT4) | |
| Installation | Wall/Pole | |
