Support MIMO 2x2 and up to 4 LPAs connection (3*4G LPAs+1*5G LPA)
Full remote-control of fiber optical repeaters
Easy for cable connection with L32 connector
Support GUI for parameter setting, status monitoring, firmware downloading, alarm indicating and other management operation
2T2R, 698-4000MHz, Sub-3G+5GNR, support up to 1* 5GNR LPA and 3*Sub-3G LPAs, modular design
| Uplink | Downlink | ||
| Frequency Range | 698 - 3800 MHz | 698 - 3800 MHz | |
| Typical Gain | -5 ± 2 dB | -5 ± 2 dB | |
| Operating Temperature Range | -40°C to +55°C |
| Storage Temperature Range | -40°C to +85°C |
|
Relative Humidity |
5% - 98% |
| Local Control | PC via LAN |
| Optical Connectors | 2 x SC/APC | |
| RF Connectors | 4 x L32 (Output to LPA) | |
| Power Connector (Output power supply to LPA) |
4 x integrated socket with power supply and communication pins (3*28V + 1*48V) | |
| Installation | Wall/Pole | |
