To adapt different application scenarios, PROSE provides welding type wall cabinet and split type wall cabinet to meet different needs of customers in terms of cost, use space and portability.
Provide a variety of wall-mounted cabinet sizes and components, flexible configuration according to different requirements.
Multiple wiring channels at upper, lower and rear to facilitate on-site wiring.
A variety of wall mounting methods for rotation, convenient operation.
Built-in side door, tool free installation and disassembly, optional lock anti-disassembly design.
The front door can be quickly disassembled without tools and can be exchanged between left and right.
The opening Angle is 180°, which is convenient for equipment installation and maintenance.
The cabinet is equipped with grounding copper nails in many places to facilitate equipment grounding.
Optional casters or adjustable feet, used to fix on the ground.
Electrostatic spray in line with European RoHS environmental standards.
| Item | Wall-mounted Cabinet |
| Static Load | Up to100kg |
| Color | Black |
| Standard | Compliance with EIA-310-E, IEC297-2, DIN41491; PART1, DIN41494; PART7, GB/T3047.2-92 standard; compatible with ETSI standard |
| Frame Structure | Split structure |
| U-column | 4pcs |
| Beam Thickness(mm) | 1.2mm |
| Front Door | Glass door(or Mesh door), Spring lock |
| Rear Door | Closed door, non-removable |
| Side Door | Tool-free installation |
| Fan | 2pcs, AC220V |
| PDU | Input 16A, output 6 multipurpose port,1.5m cable |
| Guide Rail | 1 set |
