RF radiation system protection
Operation frequency up to 4.0GHz
Inner and outer conductor DC block
| Characteristics Impedance |
50 Ω |
|
| Frequency | 0-4 GHz | |
| Power Avg. | ≥300 W | |
| Isolated DC Voltage | 3000 V (for VSWR=1.0@ sea level) | |
| Insertion Loss | ≤0.3 dB @ 0-4000MHz | |
| VSWR | ≤1.10 @ 100-1000MHz | |
| ≤1.15 @ 1000-3000MHz | ||
| ≤1.20 @ 3000-4000MHz | ||
| Intermodulation 3 rd, 2x43dBm, @1800MHz | ≤-155 dBc | |
| Interface |
DIN male, DIN female |
|
| Mating Cycles | 500 times | |
| Operating Temperature |
-40 to +85 ℃ |
|
| IP Protection | IP67 | |
| RoHS | Compliant | |
