Antenna frequency: 2 x (698-960)+4 x (1695-2690)+2 x (1695-2690) MHz
3dB azimuth beamwidth: 65/65/33 °
Gain: 16.7/18.0/19.1 dBi
Electrical downtilt: 2-12/2-12/2-10 °
Connector: 16 x 4.3-10 female
Dimension: 2690 x 498 x 197 mm
Status of product: general available
Twin Beam Antenna
Integrated RET (AISG 2.0 Compliant), field exchangeable
| Frequency | 2 x (698-960)+4 x (1695-2690)+2 x (1695-2690) MHz |
| Gain | 16.7/18.0/19.1 dBi |
| 3dB Azimuth Beamwidth | 65/65/33° |
| Electrical Downtilt | 2-12/2-12/2-10 ° |
| 1st Upper Sidelobe Suppression | > 16/> 16/> 16 dB |
| VSWR | < 1.5 |
| Intra - Cluster Isolation | > 26/> 26 /> 26 |
| Beam Isolation | / / > 16 |
| 3rd PIM(2 x 43 dBm) | < -153 dBc |
| Impedance | 50 Ω |
| Connector Type | 16 x 4.3-10 female |
| Connector Position | Bottom |
| Lightning Protection | DC ground |
| Radome Material | Fiberglass |
| Radome Color | Light grey |
| Antenna Dimensions (H x W x D) | 2690 x 498 x 197 mm | 105.9 x 19.6 x 7.8 in |
| Packing Size (H x W x D) | 2840 x 575 x 370 mm | 111.8 x 22.6 x 14.6 in |
| Survival Wind Speed | 241 km/h | 150 mph |
| Wind Load @150 km/h (Max) | 1263 N | 284 lbf |
| Mast Diameter Supported | 50 - 110 mm | 2.0 – 4.3 in |
| Relative Humidity | 5% - 95% |
| Operating Temperature Range | -40 ~ +70 °C | -40 ~ +158 °F |
| Compatible Standards | AISG2.0/ 3GPP |
| Power Consumption | ≤2(stand by); ≤13(operating) |
| Configuration Management | Integrated RET, pre-configured |
| Software Upgradability | True |
| Replaceability in Field | True |
| 698-960 | 1695-2690 | 1695-2690(Twinbeam) |
![]() |
![]() |
![]() |

| Item | Model | Weight | Mechanical Tilt Range (°) |
| Mounting Kit | 185-1 | 11.1 kg / 24.5 lb | 0-10 |
