Support n78 4x4 MIMO with 5G technology
Up to 8 x 4T4R MPRU can be connected with single PBMU/IM2U
2W comprehensive output power
Compact size with low weight
Flexible installation and maintenance
N78, 33dBm, 4T4R, 3300-3700MHz, 5GNR
| Uplink | Downlink | ||
| Frequency Range | n78 (2x2 MIMO) | 3400 - 3800 MHz | 3400 - 3800 MHz |
| Gain | 40 ± 3 dB | 40± 3 dB | |
| Max RF Power | --- | 33 ± 2 dBm | |
| Operating Temperature Range | -40ºC to +55ºC |
| Storage Temperature Range | -40°C to +85°C |
|
Relative Humidity |
5% - 95% |
|
Ingress Protection |
IP67 |
| Monitoring and Control | LAN-RJ45 (local) |
| Optical Connector | 2 x SC/APC | |
| RF Connector (Downlink Output) |
4 x 4.3-10 (ANT1: SISO_L; ANT2: MIMO_L; ANT3: SISO_H; ANT4: MIMO_H)* Note: * L means low frequency range 3300-3500MHz, H means high frequency range 3500-3700MHz, both L and H can be configurable, but the bandwidth should be lower than 200MHz. |
|
| RF Connector (Uplink Input) | 2 x 4.3-10 (ANT1 / ANT4) | |
| Installation | Wall/Pole | |
