Corrosion resistant
Electrical insulation
Impact resistant
Easy installation
Flame retardant
Rigid conduits are tough and smooth, have good effect on the resistance of rodent bite and heavy press in short-term period. Length is limited due to the hardness of the material and coupling needed in the field installation.
Common Uses:
| Material | PVC |
| Available PN | Inch | DN(mm) | De (mm) | Description |
| PR-HPP00-13-WH-3000 | - | - | 13 | PVC pipe De13mm, white, length 3m |
| PR-HPP00-16-WH-3000 | 3/8” | 10 | 16 | PVC pipe De16mm, white, length 3m |
| PR-HPP00-20-WH-3000 | 1/2” | 15 | 20 | PVC pipe De20mm, white, length 3m |
| PR-HPP00-25-WH-3000 | 3/4” | 20 | 25 | PVC pipe De25mm, white, length 3m |
| PR-HPP00-32-WH-3000 | 1” | 25 | 32 | PVC pipe De32mm, white, length 3m |
| PR-HPP00-40-WH-3000 | 1 1/4” | 32 | 40 | PVC pipe De40mm, white, length 3m |
| PR-HPP00-50-WH-3000 | 1 1/2” | 40 | 50 | PVC pipe De50mm, white, length 3m |
| PR-HPP00-63-WH-3000 | 2” | 50 | 63 | PVC pipe De63mm, white, length 3m |
| PR-HPP00-75-WH-3000 | 2 1/2” | 65 | 75 | PVC pipe De75mm, white, length 3m |
| PR-HPP00-90-WH-3000 | 3” | 80 | 90 | PVC pipe De90mm, white, length 3m |
| PR-HPP00-110-WH-3000 | 4” | 100 | 110 | PVC pipe De110mm, white, length 3m |
| PR-HPP00-140-WH-3000 | 5” | 125 | 140 | PVC pipe De140mm, white, length 3m |
| PR-HPP00-160-WH-3000 | 6” | 150 | 160 | PVC pipe De160mm, white, length 3m |
| PR-HPP00-225-WH-3000 | 8” | 200 | 225 | PVC pipe De225mm, white, length 3m |
| PR-HPP00-250-WH-3000 | 10” | 250 | 250 | PVC pipe De250mm, white, length 3m |
| PR-HPP00-315-WH-3000 | 12” | 300 | 315 | PVC pipe De315mm, white, length 3m |
| Working Temperature | -15 to +70 ℃ |
| Fire Resistance | UL94-HB |
| RoHS | Compliant |

A type of conduit used in electrical installations and cable wiring

A products designed to protect and route cables in both indoor and outdoor

A galvanized steel pipe designed to protect insulated electrical conductors and cables

A new type of conduit that combines the properties of metal and plastic
