Integrates signal conditioning and combining in a modular
Flexible platform for input to optical master unit
Supports Multi-Band and Multi-Operator applications
Accepts direct BTS signal levels between 37 to 46 dBm
Supports global bands from 617MHz to 4200MHz
Supports 5G technology
8 in 8 out, 617-4200MHz, 24dB insertion loss
|
Uplink |
Downlink | |
| Frequency Range |
617 - 4200 MHz |
617 - 4200 MHz |
|
Insertion Loss |
24 ± 3 dB |
24 ± 3 dB |
|
Operating Temperature Range |
-0°C to +45°C |
|
Storage Temperature Range |
-10°C to +55°C |
|
Relative Humidity |
5% - 90% |
|
Ingress Protection |
Indooor |
| RF Connectors |
BTS Ports |
8 x 4.3-10 Female |
| ANT Ports | 8 x SMA Female | |
| Mounting | 19' Rack Mount | |
