Indoor any purpose cable distribution;
Backbone distribution cable in a building
Comply with standard IEC 60794, IEC 60793;
LSZH jacket meet IEC 60332-1.
PROSE indoor tight-buffered distribution fiber optic cable is designed for fiber solutions with excellent performance which exceed TIA / EIA 568.3-D, ISO / IEC 11801,EN50173 requirements.
Good EMI-resistant, easy installation, meanwhile having extremely high flexibility, adaptability and maximally integrated designing.
| Items | Specification | ||||||||
| Fiber Count | 2 | 4 | 6 | 8 | 12 | 16&24 | |||
| Optical Fiber | Diameter(±5μm) | 250 | |||||||
| Tight buffer | Diameter(±50μm) | 900 | |||||||
| Color | 1. White 2. Blue 3. Orange 4. Green 5. Brown 6. Grey 7. Red 8. Black 9. Yellow 10. Violet 11. Pink 12. Aqua. |
||||||||
| Cable | Core reinforce | Aramid yarn | |||||||
| Sheath material | OFNR/OFNP/LSZH | ||||||||
| Color | Yellow (SM) - Orange (OM2) - Aqua(OM3) – Violet(OM4) | ||||||||
| Out diameter(mm) | 4.0±0.3 | 4.8±0.3 | 4.8±0.3 | 5.6±0.3 | 6.2±0.3 | 8.1±0.3 | |||
| Cable weight(kg/km) | Approx.13 | Approx.19 | Approx.22 | Approx.30 | Approx.36 | Approx.59 | |||
| Fiber Type | Single-mode G652D (1310/1550nm) |
Single-mode G657A1 (1310/1550nm) |
Single-mode G657A2 (1310/1550nm) |
|
| Attenuation(dB) | Typical | 0.36/0.22 | 0.36/0.22 | 0.36/0.22 |
| Maximum | 0.5/0.4 | 0.5/0.4 | 0.5/0.4 | |
| Zero Dispersion Slope | ≤0.091 ps/kmꞏnm2 | ≤0.092 ps/kmꞏnm2 | ≤0.092 ps/kmꞏnm2 | |
| Dispersion(1285~1340nm) | -3.5 – 3.5ps/(nmꞏkm) | -3.5 – 3.5ps/(nmꞏkm) | -3.5 – 3.5ps/(nmꞏkm) | |
| Mode Field Diameter (@1310nm) | 9.1±0.4 µm | 8.8±0.4 µm | 8.8±0.4 µm | |
| Cutoff wavelength cable(nm) | ≤1260 nm | ≤1260 nm | ≤1260 nm | |
| Min bend radius(mm) | 16mm | 10mm | 7.5mm | |
| Cladding diameter(µm) | 125±1.0 | 125±1.0 | 125±1.0 | |
| Fiber Type | Multi-mode (62.5/125µm ) (850/1300nm) |
Multi-mode (50/125µm ) (850/1300nm) |
Multi-mode OM3 (850/1300nm) |
Multi-mode OM4 (850/1300nm) |
Multi -mode OM5 (850/953nm/1300nm) |
|
| Attenuation(dB) | Typical | 3.0/1.0 | 3.0/1.0 | 3.0/1.0 | 3.0/1.0 | 3.0/-/1.0 |
| Maximum | 3.5/1.5 | 3.5/1.5 | 3.5/1.5 | 3.5/1.5 | 3.5/-/1.5 | |
| Bandwidth (MHzꞏkm) | ≥200/≥500 | ≥500/≥500 | ≥1500/≥500 | ≥3500/≥500 | ≥3500/≥1850/≥500 | |
| Effective modal bandwidth | ----/---- | ----/---- | ≥2000/---- | ≥4700/---- | ≥4700/2470 | |
| 10 Gigabit Ethernet SX (MHzꞏkm) | ---- | ---- | ≤300/---- | ≤550/---- | ≤600 | |
| Min bend radius(mm) | 30 | 30 | 7.5 | 7.5 | 7.5 | |
| Cladding diameter(µm) | 125±1.0 | 125±1.0 | 125±1.0 | 125±1.0 | 125±1.0 | |
| Items | Parameters |
| Tensile strength (Long term) | 300N |
| Tensile strength (Short term) | 1000N |
| Min bend radius(Dynamic) | 20 times O.D |
| Min bend radius(Static) | 10 times O.D |
| Crush resistance (Long term) | 200N/100mm |
| Crush resistance (Short term) | 1000N/100mm |
| Storage temperature | -40℃~+70℃ |
| Installation temperature | -20℃~+60℃ |
| Operation temperature | -20℃~+60℃ |
| Flame retardant | IEC 60332-1 |
