Low VSWR, high isolation
Low PIM, low insertion loss
Compact design for easy installation
DFT-09-64-64F-A01, a double-unit cavity filter developed for stable RF signal control, providing low VSWR, high isolation, low insertion loss, and low PIM to preserve signal quality in multi-channel operation. A space-efficient enclosure supports convenient installation, meeting the integration needs of macro base stations and cellular communication systems.
|
Frequency |
888.4-952.4MHz |
| Return Loss / VSWR | ≤-19dB /1.25 |
| Insertion Loss | ≤0.5 dB @888.4-893 MHz |
| ≤0.35 dB @893-952.4 MHz | |
| Rejection | ≥50 dB@824-880 MHz |
| Power Handling | 200W (TX band) |
| DC Bypass | DC bypass for all ports |
| Intermodulation | ≤-155dBc@2x43dBm |
| Impedance | 50Ω |
| Operating Temperature Range | -25°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5%- 95% |
| Applications | IP67 |
| Dimension | 240x198x49(mm, excluding brackets and connectors) |
| Weight | ≤3.3kg |
| Connectors Type | 4.3-10 female |
| Packing | 1Pcs in box |
