2 MPP trackers, Max. efficiency up to 98.6%
Zero export application, VSG application
String intelligent monitoring (optional)
Wide output voltage range
Anti-PID function (Optional)
This three-phase string inverter converts DC power from PV modules into grid-compliant three-phase AC power for grid connection and industrial and commercial power supply.
| Part Number | PR-DY-INS30K-2M3P | PR-DY-INS33K-2M3P | PR-DY-INS35K-2M3P | PR-DY-INS36K-2M3P |
| PV String Input Data | ||||
| Max. PV Input Power | 39 kW | 42.9 kW | 45.5 kW | 46.8 kW |
| Max. PV Input Voltage | 1100 V | |||
| Start-up Voltage | 250 V | |||
| MPPT Voltage Range | 200-1000 V | |||
| Rated PV Input Voltage | 600 V | |||
| Max. Operating PV Input Current | 40 + 40 A | |||
| Max. Input Short Circuit Current | 60 + 60 A | |||
| No. of MPP Trackers/ No. of Strings MPP Tracker | 2 / 3 + 3 | |||
| Part number | PR-DY-INS30K-2M3P | PR-DY-INS33K-2M3P | PR-DY-INS35K-2M3P | PR-DY-INS36K-2M3P |
| AC Output Side | ||||
| Rated AC Output Active Power | 30 kW | 33 kW | 35 kW | 36 kW |
| Max. AC Output Apparent Power | 33 kVA | 36.3 kVA | 38.5 kVA | 39.6 kVA |
| Rated AC Output Current | 45.5 / 43.5 A | 50 / 47.8 A | 53 / 50.7 A | 54.5 / 52.2 A |
| Max. AC Output Current | 50 / 47.9 A | 55 / 52.6 A | 58.3 / 55.8 A | 60 / 57.4 A |
| Rated Output Voltage/Range | 220 / 380 V, 230 / 400 V 0.85 Un-1.1 Un | |||
| Grid Connection Form | 3L / N / PE | |||
| Rated Output Grid Frequency/Range | 50 / 45-55 Hz, 60 / 55-65 Hz | |||
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | |||
| Total Current Harmonic Distortion THDi | < 3 % | |||
| DC Injection Current | < 0.5 %ln | |||
| Max. Efficiency | 98.6 % | ||
| European Efficiency | 98.1 % | ||
| MPPT Efficiency | > 99 % | ||
| Operating Temperature Range | -25 to 60℃, > 45℃ derating | ||
| Permissible Ambient Humidity | 0 - 100% | ||
| Permissible Altitude | 4000 m | ||
| Noise | ≤ 60 dB | ||
| Ingress Protection(IP) rating | IP 65 | ||
| Inverter Topology | Non-isolated | ||
| Over Voltage Category | OVC II(DC), OVC III(AC) | ||
| Cabinet Size (WxHxD) | 330 * 572 * 206 mm (Excluding connectors and brackets) | ||
| Weight | 28.7 kg | ||
| Type Of Cooling | Intelligent air cooling | ||
| DC Reverse Polarity Protection | YES |
| AC Output Overcurrent Protection | YES |
| AC Output Overvoltage Protection | YES |
| AC Output Short Circuit Protection | YES |
| Thermal Protection | YES |
| Insulation Impedance Detection | YES |
| DC Component Monitoring | YES |
| Anti-islanding Protection | YES |
| Residual Current Detection | YES |
| Surge Protection Level | TYPE II (DC), TYPE II (AC) |
| DC Switch | YES |
| Communication Interface | RS485 / RS232 |
| Monitor Mode | GPRS / WIFI / Bluetooth / 4G / LAN (optional) |
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard | IEC/EN 61000-6-1 / 2 / 3 / 4, IEC / EN 62109-1, IEC / EN 62109-2 |
