10 times cycle life & 5 times float life than lead-acid, lower replacement and total costs
40% lighter, direct drop-in replacement for lead-acid batteries
Double power, retains high capacity even at high discharge rate
LFP material prevents explosion and combustion from impact, overcharge and short circuit
Supports UPSOC unstable charge and discharge use
Lithium chargeable battery 48V 100A, with gyroscope anti-theft function, 3U, cycle Life≥3500 cycles @25℃, 80% DoD, 442*411*133mm.
| Nominal Voltage | 48 V |
| Nominal Capacity | 100 Ah (0.2 C, 25 ℃) |
| Energy | 4800 Wh |
| Internal Resistance (ACR) | ≤ 100 mΩ |
| Cycle Life | ≥ 3500 cycles @ 25 ℃, 80% DoD |
| Design Life | ≥ 10 years @ 25 ℃ |
| Self-Discharge (30 days) | ≤ 2 % @ 25 ℃ |
| Efficiency of Charge | ≥ 98 % |
| Efficiency of Discharge | ≥ 100 % @ 0.2 C |
| ≥ 96 % @ 1 C | |
| Charge Voltage | 54.4 - 58 V |
| Charge Mode | 0.2 C to 54 V, then 54 V charge current to 0.02 C (CC / CV) |
| Max. Continuous Charge Current | 100 A |
| Max. Continuous Discharge Current | 100 A |
| Discharge Cut-off Voltage | 42.5 ± 0.5 V |
| Water Dust Resistance | IP40 |
| Case | Iron (Insulation painting) |
| Dimensions(W*D*H) (excluding hanger and handle bar) | 442 * 411 * 133 mm |
| Max. Weight | 40 kg |
| Parallel in maximum | 15 pcs |
| Charge Temperature Range | 0 to 55 ℃ |
| Discharge Temperature Range | -20 to 55 ℃ |
| Optimum Operation Temperature | 10 to 35 ℃ |
| Storage Temperature | 0 to 40 ℃,≤ 85% Relative Humidity |
| Parallel Communication | CAN |
| Battery with Equipment | CAN / RS485 |
| Battery Debugging Communication | RS485 |
| Communication protocol | Modbus |
| Interface | RS485, CAN |
| Dry Contact |
PIN1 to PIN2: Normally closed, open during fault protection PIN3 to PIN4: Normally closed, open during low power |
| Gyroscope anti-theft | Keep battery tilt more than 15° to turn on anti-theft |
| SOC Light | 4 * LED |
| Charge Current limit | When the charging current exceeds the set value, turn on the current limit and limit the current to 15 A |
| Passed ISO9001, ISO14001, ISO45001, UL1642, CE, ROHS, IEC62619, IEC62620, UN38.3 | ||||||
| Battery cell cost advantage |

Lithium chargeable battery 48V 100A, 3U
_495x300.png)
Lithium chargeable battery 48V 150A, 3U with gyroscope anti-theft function

Lithium chargeable battery 48V 100A, 3U with gyroscope anti-theft function and GPS location support
